| Model | TM201 | |
| Chassis | SGCC 0.6mm | |
| PSU Form Factor | Bottom/TFX | |
| M/B Form Factor | Micro-ATX (Max 200*210mm)、Mini-ITX | |
| Front Panel | ABS | |
| Top Panel | metal | |
| Branding | Box | |
| Unit | ||
| (Unit) Position | ||
| Side Panel | Left | metal cover |
| Right | metal cover | |
| External Drive Bay(s) | 5.25" (Slim ODD) | *1 |
| 3.5" | *0 | |
| Internal Drive Bay(s) | 3.5" (HDD) | *1 |
| 2.5" (SSD) | *1 | |
| I/O | Buttons | *1 |
| USB1.1 Port(s) | *0 | |
| USB2.0 Port(s) | *2 | |
| USB3.0 Port(s) | *0 | |
| USB3.1 Port(s) | *0 | |
| HD Audio Support | *1 | |
| Type C | *0 | |
| P-lock | *0 | |
| Card reader | *1(optional) | |
| Security /COM port | kensington lock,Pad lock | |
| Cooling Fan Support | Front | 1x80mm(Fan optional) |
| Top | 0 | |
| Rear | 0 | |
| Left Side | 0 | |
| PSU Cover | 0 | |
| Water Cooling Support (Radiator Size) |
Front | 0 |
| Top | 0 | |
| Rear | 0 | |
| Dust Cover | 0 | |
| Slots | *2 | |
| Carton & Logo | OEM | |
| Dimensions | Chassis | (L)28 cm x (W)9.3 cm x (H)29 cm |
| Full Case (inc Fascia) | (L)31 cm x (W)9.3 cm x (H)29 cm | |
| Carton | (L)34.6 cm x (W)14.6 cm x (H)36 cm | |
| Net Weight (Kg) | kgs | |
| Gross Weight (Kg) | kgs | |
| VGA Card Length | up to 130mm | |
| CPU Cooler Height | 65mm | |
7.5L Chassis
TM201 -7.5L Desktop SFF Case
TM201 -7.5L Desktop SFF Case
Simple ,Stylish Appearance with fully Tool-less design, microATX motherboard full size support
